ICX8200-C08ZP Ruckus 4xRJ-45 PoE++ + 4×2.5GE PoE++ + 2xSFP28 Switch
ICX8200-C08ZP Overview
The Ruckus ICX8200-C08ZP is a compact enterprise-grade multi-gigabit managed switch designed for high-performance edge and campus network deployments. It features 4 × RJ-45 PoE++ Gigabit Ethernet ports and 4 × 2.5GbE PoE++ ports, providing both high-speed connectivity and power delivery for devices such as Wi-Fi 6/6E/7 access points, IP cameras, VoIP phones, and IoT equipment. The switch includes 2 × SFP28 ports supporting 10/25GbE uplinks for high-bandwidth backbone connectivity and network expansion. It supports advanced Layer 2 and Layer 3 networking features, including VLANs, QoS, routing, link aggregation, ACLs, and enhanced security controls.
ICX8200-C08ZP Technical Specification
Ruckus 4xRJ-45 PoE++ + 4×2.5GE PoE++ + 2xSFP28 Switch
Part Number: ICX8200-C08ZP
Brand: Ruckus
Ports: 4 x Gigabit PoE++ RJ-45
Multi-Gig Ports: 4 x 2.5GbE PoE++ RJ-45
Uplink Ports: 2 x 25GbE SFP28
Switching Capacity: 200 Gbps
Forwarding Rate: 148.8 Mpps
PoE Standard: IEEE 802.3af/at/bt (PoE+/PoE++)
PoE Power Budget: Up to 370W
Per Port Power: Up to 90W
MAC Address Table: 16K Entries
Jumbo Frame Support: 9KB
Management: Fully Managed
