10-2205-06 Cisco 10GBASE-SR X2 MMF 850nm 10G Transceiver Module
Out of stock
10-2205-06 Overview
The Cisco 10-2205-06 is a high-speed optical transceiver designed for 10 Gigabit Ethernet (10GbE) short-reach applications. Supporting the 10GBASE-SR standard, it operates over multi-mode fiber (MMF) and delivers data rates of 10Gbps. With an 850nm VCSEL laser transmitter, it enables transmission distances of up to 300 meters on OM3 fiber and up to 400 meters on OM4 fiber, making it well-suited for data center and enterprise deployments.This module uses the X2 form factor, a hot-swappable design that allows easy installation or replacement without disrupting network operations. It integrates a duplex SC connector, ensuring stable, low-loss connectivity for high-performance links.
10-2205-06 Technical Specifications
Cisco 10GBASE-SR X2 MMF 850nm 10G Transceiver Module
Manufacturer Part Number: 10-2205-06
Brand Name: Cisco
Product Type: X2 Transceiver Module
Data Rate: 10Gbps
Transceiver Type: 10GBase-SR (Short Reach)
Media Type Supported: Multi-Mode Fiber (MMF)
Wavelength: 850nm
Connector Type: Duplex SC
Maximum Reach: Up to 300m (OM3 MMF)
Form Factor: X2
Hot Swappable: Yes
Digital Diagnostics Monitoring (DOM): Supported
Fiber Strand Count: 2 (duplex)
Compatibility: Cisco switches and routers supporting X2 modules
Application: Data center, enterprise LAN, and short-haul backbone connectivity
Standards Compliance: IEEE 802.3ae 10GBase-SR, X2 MSA
Backward Compatibility: Supports legacy 1Gbps Ethernet where applicable
Power Consumption: Optimized for low power use
Operating Temperature: 0°C to 70°C
Storage Temperature: -40°C to 85°C
Reliability: High-performance optical design for continuous operation
Installation: Plug-and-play module
