774174-001-AM AddOn 32GB DDR4-2133MHz ECC Memory Module
774174-001-AM Overview
The is a high-quality compatible 32GB DDR4-2133MHz Load-Reduced ECC LRDIMM from AddOn Networks. It is specifically designed as a direct replacement or upgrade for HPE ProLiant Gen9 series servers that support high-density load-reduced memory. This quad-rank x4, low-voltage (1.2V) module with CL15 latency enables greater memory capacity per channel while delivering reliable error-correcting performance essential for enterprise data centers, virtualization, large databases, cloud computing, and mission-critical applications where maximum RAM density and system stability are required. Although DDR4-2133 is now a previous-generation speed compared to faster DDR4 and current DDR5 modules, this LRDIMM remains an excellent and cost-effective solution for maintaining, repairing, or expanding the memory capacity of older HPE ProLiant Gen9 servers.
$399
774174-001-AM Technical Specifications
AddOn 32GB PC4-17000 DDR4-2133MHz ECC Registered CL15 288-Pin Load Reduced DIMM 1.2V Quad Rank Memory Module
Maunfatcurer: AddOn
Manufacture Part Number: 774174-001-AM
Capacity: 32GB (1 x 32GB)
Memory Type: DDR4 SDRAM
Speed: 2133MHz (PC4-17000 / PC4-17000P-L)
Form Factor: 288-pin LRDIMM (Load-Reduced DIMM)
Rank: Quad Rank (4Rx4)
Voltage: 1.2V
CAS Latency: CL15
Buffered/ECC: Load-Reduced ECC
