9581-0-24-9W Omnitron Systems 10GPoE+/Sx Unmanaged Switch 4x Gigabit PoE+ Ports
9581-0-24-9W Overview
The Omnitron Systems 9581-0-24-9W OmniConverter 10GPoE+/Sx is an unmanaged Ethernet switch designed for reliable network connectivity and high-speed data transmission in demanding environments. It provides 4 Gigabit PoE+ ports for connecting and powering compatible devices such as IP cameras, wireless access points, VoIP phones, and other PoE-enabled equipment, while 2 dedicated 10G SFP+ slots deliver fast fiber uplink connectivity for bandwidth-intensive network applications. Its wide-temperature design makes it suitable for installations where operating conditions may vary, including industrial, outdoor, and other challenging environments. With a simple plug-and-play design, the Omnitron OmniConverter 10GPoE+/Sx offers a practical solution for expanding network infrastructure while supporting both Gigabit PoE+ connectivity and 10Gbps SFP+ uplinks.
$1,253
9581-0-24-9W Technical Specifications
Omnitron Systems OmniConverter 10GPoE+/Sx Unmanaged Switch 4x Gigabit PoE+ Ports, 2x 10G SFP+ Slots Wide Temp
Product Line: OmniConverter
Product Series: 10GPoE+/Sx
Product Model: 9581-0-24-9W
Package Type: Retail
Product Type: Ethernet Switch
Interfaces/Ports
Total Number of Network Ports: 6
Uplink Port: Yes
Modular: Yes
I/O Expansions
Total Number of Expansion Slots: 2
Expansion Slot Type: SFP+
Number of SFP+ Slots: 2
Media & Performance
Media Type Supported: Optical Fiber, Twisted Pair
Ethernet Technology: Gigabit Ethernet, 10 Gigabit Ethernet
Network & Communication
Layer Supported: 2
Power Description
PoE (RJ-45) Port: Yes
PoE Budget: 30 W
Power Source: DC
Plug / Connector Type: Terminal Block (2 Wire)
Management & Protocols
Manageable: No
Physical Characteristics
Form Factor: Wall Mountable, DIN Rail Mountable, Shelf Mountable, Rack-mountable
Height: 1.5″
Width: 6.3″
Depth: 5.2″
