FTLF8532P4BCV-QM Qlogic 32G Fibre Channel Short-Wavelength SFP
Out of stock
FTLF8532P4BCV-QM Overview
The FTLF8532P4BCV-QM QLogic 32G Fibre Channel Short-Wavelength SFP is a high-speed optical transceiver engineered to deliver reliable and efficient connectivity for enterprise Fibre Channel storage networks. Designed to support 32G Fibre Channel applications, this short-wavelength transceiver operates over 850nm multimode fiber (MMF) and provides dependable data transmission for distances up to 100 meters using OM4 fiber. Its hot-pluggable form factor allows for quick installation and seamless integration with compatible QLogic Fibre Channel switches, storage systems, and host bus adapters. Featuring low power consumption, digital diagnostic monitoring (DDM), and consistent high-performance operation, the FTLF8532P4BCV-QM is an ideal choice for modern data centers that require fast, stable, and scalable SAN connectivity while minimizing network latency and maximizing storage performance.
FTLF8532P4BCV-QM Technical Specifications
Qlogic 32G Fibre Channel Short-Wavelength SFP
Manufacturer : Finisar / QLogic
Manufacturer Part Number : FTLF8532P4BCV-QM
Product Name : QLogic 32Gb Fibre Channel Short-Wavelength SFP+ Optical Transceiver
Product Type : SFP+ Transceiver Module
Form Factor : Plug-in Module
Hot-Swappable : Yes
Connectivity Technology : Wired
Cabling Type : 32Gb Fibre Channel
Data Link Protocol : 32Gb Fibre Channel (Short-Wavelength)
Data Transfer Rate : 28.05 Gbps / 32 Gbps (Tri-Rate: 8.5 Gbps, 14.025 Gbps, 28.05 Gbps)
Optical Wave Length : 850 nm
Max Transfer Distance : 70 meters (OM3 MMF) / 100 meters (OM4 MMF)
Interfaces / Ports Details : 1 x 32Gb Fibre Channel – LC Multi-Mode
Connector Type : LC Duplex
Media Type Supported : Optical Fiber
Fiber Mode Supported : Multi-mode Fiber (MMF)
Transceiver Type : Short-Wavelength (SW / SR)
