KCD5XLUG3T84 Toshiba CD5 Series 3.84TB TLC PCI Express Internal Solid State Drive
KCD5XLUG3T84 Overview
The KCD5XLUG3T84 (Toshiba/Kioxia CD5 Series 3.84TB) is an enterprise-class internal U.2 2.5-inch NVMe PCIe 3.0 x4 SSD engineered for high-capacity, read-intensive cloud and datacenter workloads. Built with premium BiCS FLASH 3D TLC NAND, it delivers high-throughput, low-latency performance optimized for applications like content delivery networks (CDNs), web servers, and large-scale data warehousing. This model features Sanitize Instant Erase (SIE), which allows for instant cryptographic deletion of data for secure decommissioning or rapid drive reallocation. Engineered for relentless 24/7 server environments, it includes crucial enterprise-grade safeguards like power-loss data protection and end-to-end data path protection to guarantee data integrity.
$1,749
KCD5XLUG3T84 Technical Specification
Toshiba CD5 Series 3.84TB TLC PCI Express 3.0 x4 NVMe Read Intensive (SIE) U.2 2.5-inch Internal Solid State Drive
General Information
Manufacturer: Toshiba / Kioxia
Product Line: CD5 Series Data Center NVMe SSD
Part Number: KCD5XLUG3T84
Product Name: Toshiba CD5 3.84TB PCIe Gen3 x4 U.2 Enterprise Solid State Drive
Technical Information
Storage Capacity: 3.84TB (3840GB)
Memory Technology: 64-Layer BiCS FLASH 3D TLC Memory
Interface Type: PCIe Gen3 x4 (Single-port support, NVMe Rev. 1.3a compliant)
Form Factor: 2.5-inch Small Form Factor (15mm enterprise Z-height)
Physical Interface Connector: U.2 (SFF-8639)
Performance Metrics
Sustained Sequential Read Speed: Up to 3,140 MB/s
Sustained Sequential Write Speed: Up to 2,580 MB/s
Sustained Random Read: Up to 550,000 IOPS
Sustained Random Write: Up to 50,000 IOPS
