KCMYXVUG3T20 KIOXIA 3.2tb Pcie 5.0 Nvme 2.5 Inch Solid State Drive
KCMYXVUG3T20 Overview
The KIOXIA KCMYXVUG3T20 CM7‑V Series 3.2 TB PCIe 5.0 NVMe SSD is a high‑performance enterprise‑class internal solid‑state drive built for modern mixed‑use server and data‑center workloads. It uses a PCIe 5.0 ×4 NVMe 2.0 interface and comes in a 2.5‑inch, 15 mm U.3 form factor, making it compatible with hot‑swappable enterprise drive bays and storage arrays. The drive is built on KIOXIA’s 112‑layer BiCS FLASH™ 3D TLC NAND, delivering a strong balance of capacity, performance, and endurance suitable for applications like virtualization, databases, cloud services, analytics, and online transaction processing.
$2,599
KCMYXVUG3T20 Overview
KIOXIA 3.2tb Cm7-v Series Pcie 5.0 Nvme 2.0 2.5 Inch 15mm Thickness Mixed Use Enterprise 3 Dwpd Sie Model Solid State Drive
Manufacturer : KIOXIA
Manufacturer Part : KCMYXVUG3T20
Form Factor : 2.5-inch, 15mm Thickness
Lnterface : Pcie® 5.0, Nvme™ 2.0
Maximum Interface Speed : 128 Gt/s (pcie® Gen5 Single X4, Dual X2)
Flash Memory Type : Bics Flash™ Tlc
Performance In Single Port (1×4) Mode (up To) :
Sustained 128 Kib Sequential Read : 14,000 Mb/s
Sustained 128 Kib Sequential Write : 6,750 Mb/s
Sustained 4 Kib Random Read : 2,700k Iops
Sustained 4 Kib Random Write : 600k Iops
Power Requirements
Supply Voltage : 12 V ± 10 %, 3.3 V ± 15 %
Power Consumption (active) : 25 W Typ.
Power Consumption (ready) : 5 W Typ.
Reliability :
Mttf : 2,500,000 Hours
Dwpd : 3
Dimensions :
Thickness : 15.0 Mm +0 / -0.5 Mm
Width : 69.85 Mm ± 0.25 Mm
Length : 100.45 Mm Max
Weight : 130 G Max
