M393A8K40B22-CWD Samsung 64GB PC4-21300 DDR4-2666MHz


M393A8K40B22-CWD Overview

Samsung Registered DIMMs (or RDIMMs) are designed with an additional hardware register between the DRAM module and the system’s memory controller. RDIMMs present several advantages for the system, such as a lower electrical load on the memory controller and sustained stability even with an increase in the number of installed memory modules. Thus, RDIMMs are often the default choice for deployment in server-class computing systems. In addition to Registered DIMM’s features, Samsung memory provides an optimized solution for highly virtualized environments, high-performance computing and networking. Semiconductor modules of Samsung memory are designed with improved system circuit architecture to deliver higher performance with low power requirements.

$658

M393A8K40B22-CWD Technical Specifications

Samsung 64GB PC4-21300 DDR4-2666MHz

Manufacturer: Samsung Consumer Storage
Brand: Samsung
Product Line: Samsung
Packaged Quantity: 1
RAM
Type: DRAM
Product Type: Memory module
Form Factor: DIMM 288-pin
Module Height (inch): 1.23
Technology: DDR4 SDRAM
Storage Capacity: 64 GB, 64 GB
Registered or Buffered: Registered
Data Integrity Check: ECC
Module Configuration: 8192 x 72
Chips Organization: 8192 x 4
Memory Speed: 2666 megahertz
Memory Specification Compliance: PC4-21300
Supply Voltage: 1.2 volt
CAS Latency: CL22
Latency Timings: 22-19-19
RAM Features: On-Die Termination (ODT), Quad rank, Serial Presence Detect (SPD), Sixteen banks, Temperature monitoring, Through Silicon Via (TSV) technology
Upgrade Type: Generic
