R1N94A HPE 100Gbps 100GBase-LR Single-mode Fiber 10km 1295.56TX/ 1304.58RXnm Transceiver Module
Out of stock
R1N94A Overview
The HPE R1N94A is a high-speed QSFP28 optical transceiver designed for 100 Gigabit Ethernet (100GbE) applications over single-mode fiber (SMF). It supports long-distance links of up to 10 kilometers, making it ideal for enterprise data centers, WANs, and high-performance backbone networks.Operating with a duplex LC connector, the module uses a wavelength-division multiplexing (WDM) approach with a 1295.56nm TX and 1304.58nm RX wavelength pair to ensure reliable, low-latency optical transmission. The fully complies with IEEE 802.3ba 100GBase-LR4 standards and QSFP28 MSA specifications, guaranteeing interoperability with HPE switches, routers, and other compatible 100GbE networking devices.
R1N94A Technical Specifications
HPE 100Gbps 100GBase-LR Single-mode Fiber 10km 1295.56TX/ 1304.58RXnm Duplex LC Connector QSFP28 Transceiver Module
Manufacturer Part Number: R1N94A
Brand Name: HPE
Product Type: QSFP28 Transceiver
Data Rate: 100Gbps
Transceiver Type: 100GBase-LR (Long Reach)
Media Type Supported: Single-Mode Fiber (SMF)
Wavelength: 1295.56TX / 1304.58RX nm
Connector Type: Duplex LC
Maximum Reach: Up to 10km
Form Factor: QSFP28
Hot Swappable: Yes
Digital Diagnostics Monitoring (DOM): Supported
Fiber Strand Count: 2 (duplex)
Compatibility: HPE switches and routers
Application: Data center and high-speed network connectivity
Standards Compliance: IEEE 802.3ba, QSFP28 MSA
Forward Error Correction: Supported
Operating Temperature: 0°C to 70°C
