P20015-S21 HPE 960GB PCI Express Gen4 NVMe 2.5-inch SSD
P20015-S21 Overview
The HPE P20015-S21 960GB PCIe Gen4 NVMe Read Intensive U.3 2.5-inch Internal Solid State Drive (SSD) with Smart Carrier is an enterprise-grade, high-performance storage solution designed for HPE ProLiant Gen10 Plus and Gen11 servers. Featuring the PCIe 4.0 x4 NVMe interface, it delivers ultra-fast data access, low latency, and exceptional IOPS, making it ideal for read-intensive workloads like virtualization, cloud computing, database analytics, and boot operations.
With a 960GB capacity, the drive provides an optimal balance of performance and storage density. Its U.3 2.5-inch Small Form Factor (SFF) ensures compatibility with modern server architectures, while the Smart Carrier (SC) offers LED indicators for drive activity and health monitoring, simplifying maintenance and system management.
$1,892
P20015-S21 Technical Specifications
HPE 960GB PCI Express Gen4 NVMe Read Intensive U.3 2.5-inch Internal Solid State Drive (SSD) with Smart Carrier
Part Number: P20015-S21
Brand: HPE
Capacity: 960GB
Interface: PCI Express 4.0 x4 (NVMe)
Form Factor: 2.5-inch Small Form Factor (SFF)
Connector Type: U.3 Universal Interface
Drive Type: Read Intensive (RI) Solid State Drive
Data Transfer Rate: Up to 32Gbps (PCIe Gen4 x4)
Sequential Read Speed: Up to 6,500 MB/s
Sequential Write Speed: Up to 2,000 MB/s
Random Read (4K): Up to 850,000 IOPS
Random Write (4K): Up to 100,000 IOPS
Endurance Rating: 1 DWPD (Drive Write Per Day)
NAND Flash Type: 3D TLC NAND
Latency (Read/Write): <0.1 ms / <0.2 ms
Power Consumption (Active): ~9W typical
Power Consumption (Idle): ~3.5W typical
Reliability (MTBF): 2 Million Hours
Operating Temperature: 0°C to 70°C
Hot-Pluggable: Yes
