HP-P45669-001
,

P45669-001 HP 400Gb/s 2x400GBase-XOSFP Transceiver

Availability:

Out of stock
Compare

P45669-001 Overview

The HP P45669-001 is a high-capacity optical transceiver module designed for 400 Gigabit Ethernet deployments in next-generation data center and high-performance computing environments. Supporting the 2x400GBase-X OSFP standard, it delivers extreme bandwidth density and efficiency for backbone, interconnect, and aggregation links.Operating over single-mode fiber (SMF), this transceiver uses advanced parallel optics and high-speed modulation to achieve ultra-low latency and consistent performance across extended reaches (distance dependent on fiber type and application). It integrates MPO/MTP high-density connectors to handle the multi-lane architecture required for 400G transmission.

P45669-001 Technical Specifications

HP 400Gb/s 2x400GBase-XOSFP Transceiver

Manufacturer Part Number: P45669-001
Brand Name: HP
Product Type: OSFP Transceiver
Data Rate: 400Gbps (2x 400G channels)
Transceiver Type: 400GBase-X (XOSFP)
Media Type Supported: Single-Mode Fiber (SMF)
Wavelength: 1310nm
Connector Type: MPO/MTP
Maximum Reach: Up to 500m (depending on fiber type)
Form Factor: OSFP
Hot Swappable: Yes
Digital Diagnostics Monitoring (DOM): Supported
Fiber Strand Count: 8 or 16 (depending on configuration)
Compatibility: HP data center switches and high-capacity networking devices
Application: High-speed data center interconnect and backbone networking
Standards Compliance: IEEE 802.3bs, OSFP MSA
Backward Compatibility: Not applicable (400G-specific)
Operating Temperature: 0°C to 70°C

SKU: P45669-001 Categories: , Tags: , , ,
