Refurbished 388394-003 HP Proliant 6400r 2p Intel Xeon

Refurbished 388394-003 Technical Specifications

HP Proliant 6400r 2p Intel Xeon Piii 550MHz 1GB RAM Ultra Wide Scsi 24x cd ROM Fdd 4way Computing Power Rack Server.

GENERAL INFORMATION:
Manufacturer: Hewlett-Packard
Manufacturer Part Number: 388394-003
Product Name: Proliant 6400r Server
PROCESSOR & CHIPSET:
Installed Processor : (2) Intel Pentium 3 Xeon 550 Mhz Standard
Max Supported Qty : 4
Upgradability: Upgradable
CACHE MEMORY:
Type: L2 Cache – Pipeline Burst
Installed Size: 4 Mb (Installed) / 8 Mb (Max)
Mainboard:
Data Bus Speed: 100 Mhz
RAM:
Installed Size: 1 Gb / 4 Gb (Max)
Technology: Edo Ram – Ecc
Form Factor: Dimm 168-Pin
Features: Buffered
Upgrade Rule: 4 Modules At A Time
STORAGE CONTROLLER:
Raid Controller: Smart Array 5i Plus Controller (Integrated On System Board)
Raid Level: Raid 0, Raid 1, Raid 5, Raid 10
STORAGE CONTROLLER:
Hard Drive: None
Type: 1 X Scsi – Integrated – Pci
Hard Drive Interface: Ultra Wide Scsi
Channel Qty: 2
STORAGE CONTROLLER(2ND):
Type: 1 X Ide – Integrated – Pci
Optical Storage: 24x Ide Cd-Rom – Ide
Floppy Drive: 3.5 1.44 Mb Floppy
DISPLAY & GRAPHICS:
Type: Pci – Integrated
Installed Size: 2 Mb / 2 Mb (Max)
Supported Display Graphics: Vga (640×480), Xga (1024×768), Svga (800×600), Sxga (1280×1024)
Video Output Supported: Rgb
NETWORKING:
Networking: Pci 64 – Plug-In Card
Data Link Protocol: Ethernet, Fast Ethernet
Compliant Standards: Ieee 802.3, Ieee 802.3u
I/O EXPANSION
Expansion Bays Total (Free):
1 ( 0 ) X Front Accessible – 5.25 X 1/3h
4 ( 4 ) X Hot-Swap
1 ( 0 ) X Front Accessible – 3.5 X 1/3h
EXPANSION SLOTS TOTAL (FREE):
1 ( 0 ) X Memory Board
16 ( 12 ) X Memory – Dimm 168-Pin
4 ( 2 ) X Processor – Slot 2
5 ( 4 ) X Pci 64 Hot-Plug – Full-Length
1 ( 1 ) X Shared Pci 64 / Isa – Full-Length
INTERFACES / PORTS:
1 X Storage – Ultra Wide Scsi – 68 Pin Vhdci (Mini-Centronics)
2 X Network – Ethernet 10base-T/100base-Tx – Rj-45
1 X Parallel – Ieee 1284 (Epp/Ecp) – 25 Pin D-Sub (Db-25)
1 X Serial – Rs-232 – 9 Pin D-Sub (Db-9)
1 X Keyboard – Generic – 6 Pin Mini-Din (Ps/2 Style)
1 X Mouse – Generic – 6 Pin Mini-Din (Ps/2 Style)
1 X Display / Video – Vga – 15 Pin Hd D-Sub (Hd-15)
POWER DESCRIPTION:
Device Type: Power Supply
Installed Qty: 1
Max Supported Qty: 2
Voltage Required: Ac 110/220 V ( 50/60 Hz )
Power Provided: 450 Watt
